The Ducati MIG-S is ready to take you on all your off-road adventures.

Designed for mountain slopes and trails
6061 aluminium frame with CNC machined parts
Pirelli tyres specifically developed for e-bikes
Long lasting Shimano 630Wh battery
Shimano Steps EP8

Shimano Steps EP8

Ducati MIG-S

A benchmark in the category thanks to its low weight of 2.6 kg, its compact size and a Q factor of only 177 mm. With a maximum torque of 85 Nm and an assistance ratio of up to 400%, this drive unit ensures great pedalling power with always fluid, direct and natural delivery, for complete control of the vehicle. Combined with the Shimano E-tube Project App, the EP8 system allows advanced levels of customization to adapt the character of the engine to your needs. All our e-mtb come with two pre-set profiles: “long ride” to favour long distances and “fast ride” for greater engine responsiveness.

Frame

Frame

Ducati MIG-S

Forged and CNC machined parts with variable thickness hydroformed tubes. The geometries of the frame, with a 66° head angle, an elongated top tube and a 74.7° vertical seat tube, ensure pedalling efficiency and control of the vehicle even on the most technical passages.

More

More

Ducati MIG-S

High-level like the KS dropper post with remote handlebar control, the powerful and modular SRAM Guide T 4-piston brakes and the SRAM NX 12-speed rear derailleur (11-50T) that ensure great performance and safety in all conditions. The 630Wh battery positioned below the down tube, as well as being quick and easy to remove, ensures a very low centre of gravity, maximizing handling and stability.

Specifications & Geometry

Frame

Alloy frame 6061 with 140 mm rear travel, forged and CNC parts, hydroformed tubes

Engine

Shimano Steps EP8 (250Watt - 85Nm - 2,6kg)

Battery

Shimano 630Wh

Suspension

Front: RockShox 35 RC fork - Air, 150mm customized tuning Rear: RockShox Deluxe Select R air, 140 mm travel, custom tuned, metric 210 x 55 mm

Rear Suspension Layout

TPS Thok Progressive System (Horst Link)

Brakes

Sram Guide T - 4 calipers - 203mm rotor disks

Wheels

Thok e-plus - 29” front and 27,5” rear

Tyres

Rear tyre: PIRELLI Scorpion S 29"x2.6 SmartGrip Hyperwall Front tyre: PIRELLI Scorpion S 27,5"x2.6 SmartGrip Hyperwall

Seat Post

KS E20I telescopic dropper-post (125-150 mm)

Handlebar

Thok 780mm alloy oversize, 35mm section, 20mm rise

Weight

22,5 kg (size M without pedals)

Display

SHIMANO - Display SC-E7000 LCD display with remote control E7000

Transmission

Sram SX, 12 speed (11-50)

Rider Height
S: 5’-5’5”
M: 5’5” - 5’7”
L: 5’7”-6’
XL: 6' and over
Size
S
M
L
XL
D - Seat Tube Length - Centre to Top
400
435
470
520
A - Top Tube Length , Horizzontal
560
600
630
665
M - Bottom Bracket Height (mm)
350
350
350
350
H - BB Drop (mm)
13
13
13
13
E - ChainStay Length (mm)
450
450
450
450
G - Seat Tube Angle
74,7°
74,7°
74,7°
74,7°
F - Head Tube Angle
66°
66°
66°
66°
K - Head Tube Length (mm)
100
110
130
150
I - Fork Height
552
552
552
552
C - Wheel Base (mm)
1165
1189
1220
1255
B - Stack (mm)
596
606
624
642
Reach (mm)
413
432
456
483
Crank Length (mm)
165
165
165
165
Stem Length (mm)
45
45
45
45
Handlebar Width (mm)
780
780
780
780
Fork Offset (mm)
44
44
44
44
Standover
810
810
810
810
L - Trail
114,6
114,6
114,6
114,6

Reserve your bike

Ducati MIG-S

1

Pay a deposit to reserve your bike

2

We will contact you to arrange a fitting

3

Collect your bike once payment is complete

Full price

£5,590

Deposit

£559



Production is limited with approx. 6 month lead times – Order now to reserve your e-bike
